DataVideo WR-600 (VZ-3102052)

Command up to four PTZ cameras from up to 90 meters away with the DataVideo WR-600, a wireless controller built around a precise 3-axis joystick and a 2.4 GHz RF link that eliminates cable clutter. The integrated LCD screen gives you instant feedback on camera selection, preset recall, and battery status, while the rechargeable Li-ion cell keeps you running for up to 7 hours on a single charge.

Overview

The WR-600 is a professional-grade PTZ camera controller designed for live production, broadcast, education, and house of worship environments. It supports both wired RS-422/485 via RJ-45 and wireless 2.4 GHz RF operation, giving you flexible deployment options. The controller communicates using industry-standard VISCA and DVIP protocols, ensuring compatibility with a wide range of PTZ cameras from DataVideo and other manufacturers.

What stands out

• 3-axis joystick for simultaneous pan, tilt, and zoom control with variable speed.
• Wireless range up to 90 m (300 ft) line of sight, ideal for large venues.
• Supports up to 4 cameras with quick selection buttons and up to 255 presets per camera.
• Built-in LCD display for clear status and menu navigation.
• Rechargeable battery provides up to 7 hours of cordless operation; charges in approximately 3 hours.
• Dual control modes: wireless RF or wired RJ-45 (RS-422/RS-485).
• Comprehensive camera adjustments: focus, iris, gain, white balance, and more.

Technical details

• Control Type: Wired / Wireless
• Wireless Technology: 2.4 GHz RF
• Wireless Range: Up to 90 m (300 ft) line of sight
• Wired Interface: RJ-45 (RS-422/RS-485)
• Supported Protocols: VISCA, DVIP
• Controllable Cameras: Up to 4 (selectable)
• Control Functions: Pan, Tilt, Zoom, Focus, Iris, Gain, White Balance, Presets
• Joystick: 3-Axis (Pan/Tilt/Zoom)
• Preset Positions: Up to 255 per camera (with quick access buttons)
• Display Type: LCD
• Power Input: 12V DC
• Power Consumption: 5W
• Battery Type: Internal Rechargeable Li-ion
• Battery Life: Up to 7 hours (wireless mode)
• Charging Time: Approx. 3 hours
• Operating Temperature: 0 to 40°C (32 to 104°F)
• Mounting: Desktop

Our verdict

The DataVideo WR-600 strikes an excellent balance between wireless convenience and precise PTZ control. Its long-range RF link, robust joystick, and extensive preset support make it a reliable choice for multi-camera productions where mobility matters.
