Cutie de conectare Mennekes 18636

Electricians and facility managers install the Mennekes Anschlussbox 18636 as a robust wall-mounted CEE socket for industrial power distribution. It provides a 16 A, 5-pole, 400 V connection with a 6h clock position, suitable for three-phase equipment in workshops, commercial kitchens, and outdoor areas where splash protection is required.

Key specifications

• Socket type: CEE wall-mounted socket
• Current rating: 16 A
• Voltage: 400 V
• Poles: 5-pole (3P+N+PE)
• Clock position: 6h
• IP protection: IP44
• Housing material: Polyamide (PA6)
• Contact material: Brass
• Connection: Screw terminals, 1.5 - 4 mm²
• Cable entries: 2x M25 top/bottom, 1x M25 rear (knock-outs)
• Housing colour: Grey (RAL 7035), lid blue (RAL 5015)
• Mounting: Wall-mounted
• Operating temperature: -25°C to +40°C
• Impact resistance: IK08
• Glow wire test: 850 °C
• Cover: Hinged cover

Why choose it

The polyamide housing withstands mechanical impact and harsh environments, while the hinged cover protects the socket when not in use. Screw terminals accept conductors from 1.5 to 4 mm², simplifying installation in distribution boxes or surface-mounted setups.

Ideal use cases

• Three-phase power supply for industrial machines
• Outdoor electrical connections in protected areas
• Commercial kitchen equipment requiring 400 V
• Workshop and garage power outlets

Good to know

The 6h clock position ensures correct phase alignment for standard three-phase loads. Multiple cable entry options allow flexible wiring from top, bottom, or rear. The IP44 rating makes it suitable for use in environments with occasional splashing water.
